Apex Legends FPS Boost Guide (2026) — Get More FPS on Windows 11

Apex Legends is one of the most CPU-intensive battle royale games available — the combination of player physics, audio tracking, and hit detection pushes even mid-range systems hard. Default Windows settings and out-of-box Apex configurations leave 30–60% of your available performance unused.

This guide covers every setting and tweak in order of impact. Work through it top to bottom and you'll see the difference before you finish.

In-Game Settings — Every Option Explained

Open Settings → Video in Apex. These settings maximize FPS while keeping the visual information you need for competitive play:

| Setting | Recommended Value | Why | |---------|-------------------|-----| | Display Mode | Full Screen | Exclusive fullscreen gives the GPU priority over Desktop Window Manager | | Resolution | Native | Never scale down resolution | | Field of View | 90–110 | Adjust to preference; higher FOV slightly reduces FPS | | V-Sync | Disabled | Adds input lag and caps FPS — use G-Sync or FreeSync instead | | Adaptive Resolution FPS Target | 0 (Disabled) | This dynamically lowers resolution to hit an FPS target — disable it entirely | | Anti-Aliasing | TSAA | Best balance of quality and performance; None is marginally faster but causes shimmering | | Texture Streaming Budget | Match your VRAM | 4 GB VRAM → 2 GB; 8 GB VRAM → 4 GB | | Texture Filtering | Anisotropic 4x | Diminishing returns above 4x | | Ambient Occlusion Quality | Disabled | High GPU cost, zero competitive advantage | | Sun Shadow Coverage | Low | Shadows are the single biggest FPS drain | | Sun Shadow Detail | Low | Same | | Spot Shadow Detail | Disabled | No competitive value | | Volumetric Lighting | Disabled | Expensive; competitive players universally disable this | | Dynamic Spot Shadows | Disabled | — | | Model Detail | Low | Enemies render at the same apparent size — fewer triangles means faster | | Effects Detail | Low | Particle effects can obscure vision at High | | Impact Marks | Disabled | Zero competitive value | | Ragdolls | Disabled | Zero competitive value |

These changes alone typically add 20–40 FPS on mid-range GPUs.

Windows Power Plan — Ultimate Performance

Windows defaults to Balanced power mode, which throttles CPU clock speeds between frames to save electricity. On a gaming desktop this introduces clock ramp-up latency that appears as microstutter.

1. Press Win + R, type powercfg.cpl, press Enter
2. Click Show additional plans
3. Select High Performance or Ultimate Performance

If Ultimate Performance is not listed, enable it via PowerShell (run as Administrator):

powercfg -duplicatescheme e9a42b02-d5df-448d-aa00-03f14749eb61

Refresh Power Options and select it.

Typical gain: 5–15% FPS on systems that were throttling between frames.

NVIDIA Reflex — Reduce System Latency

NVIDIA Reflex reduces the time between your mouse input and the frame appearing on your monitor. This doesn't always raise your FPS counter, but it makes the game feel significantly more responsive — aim registers faster, movement feels immediate.

In Apex Settings → Video:

• NVIDIA Reflex Low Latency → On + Boost

"On" activates latency reduction. "Boost" additionally prioritizes GPU compute. Use both on any NVIDIA GPU that supports it (GTX 900 series and newer).

AMD Anti-Lag (AMD GPUs)

If you have an AMD GPU, open AMD Radeon Software → Gaming → Apex Legends → Graphics and enable Anti-Lag. This is AMD's equivalent to NVIDIA Reflex.

Hardware-Accelerated GPU Scheduling (HAGS)

HAGS moves GPU scheduling work off the CPU, reducing overhead in GPU-bound scenarios.

• RTX 3000/4000 series or RX 6000/7000 series: Enable HAGS
• GTX 10/16 series, RX 5000 series or older: Leave disabled — causes stuttering on pre-2020 GPUs

To toggle: Settings → System → Display → Graphics → Default graphics settings → Hardware-accelerated GPU scheduling

Restart after changing. If you enable HAGS on an AMD system and see new stuttering in Apex, disable it — Apex has a known interaction with AMD HAGS on some driver versions.

Disable Xbox Game Bar and Background Capture

Xbox Game Bar hooks into every running process. Its background video recording (GameDVR) actively compresses gameplay footage to disk while you play — even if you never open it.

1. Settings → Gaming → Xbox Game Bar → Off
2. Settings → Gaming → Captures → Record in the background while I'm playing a game → Off

This frees CPU time and eliminates the disk I/O spikes from background video compression.

Background Process Cleanup

Close these before launching Apex:

Close completely — not just minimize:

• Chrome, Firefox, Edge: browsers use 200–500 MB RAM and generate background network traffic
• Spotify: streams data and decodes audio continuously
• OneDrive: syncs files in the background

Disable GPU acceleration in Discord: Discord → Settings → Advanced → Hardware Acceleration → Off. Discord's GPU acceleration runs a separate render pass that competes with Apex for GPU memory bandwidth.

Kill via Task Manager if running:

• CORSAIR iCUE, Razer Synapse, ASUS Aura Sync — RGB software polls hardware on a 100ms timer
• GeForce Experience overlay (if not using Reflex) — the overlay has its own render layer
• steamwebhelper.exe — the Steam UI browser process (not the game itself, just the Steam store interface)

On a 16 GB system, this cleanup typically frees 600 MB–1.2 GB RAM before Apex launches.

SageTweaks — Automate the Windows Layer

Every Windows-level tweak in this guide — power plan, HAGS configuration for your GPU generation, Xbox Game Bar, GameDVR, startup cleanup, driver power settings, timer resolution — is applied automatically by SageTweaks in under 5 minutes.

It detects your GPU generation and applies the correct HAGS setting automatically. You don't need to know whether your GPU supports HAGS or which power plan to use. SageTweaks handles the OS layer; the in-game settings and RAM slot configuration are still yours to set.

For the full breakdown of how much FPS you can realistically expect from optimization, see how much FPS gain Windows optimization delivers.

Frequently Asked Questions

Will these settings get me banned in Apex Legends? No. Every tweak in this guide modifies Windows system settings or in-game graphics options. Nothing touches game files, memory, or network packets. These are the same settings used by professional Apex players and streamers.

How much FPS can I expect on a low-end PC (GTX 1060, 8 GB RAM)? On GTX 1060-class hardware with a 4-core CPU, this guide typically adds 20–40 FPS from a stock configuration. The biggest gains come from disabling shadows and effects in-game, and the power plan change. On low-end hardware, aim for 60–90 FPS at 1080p Low with these settings.

What FPS cap should I use in Apex? Cap at your monitor's refresh rate. For a 144 Hz monitor, set the cap to 144 in Apex's FPS limit slider. Running uncapped above your monitor's refresh rate generates unnecessary heat and GPU load without a visible benefit.

Does Apex Legends support DLSS or FSR? Apex Legends does not support DLSS or FSR as of 2026. The game uses TSAA for anti-aliasing. If Respawn adds upscaling support in a future update, DLSS Quality mode would be the right starting point for NVIDIA RTX users.

I still have stuttering after following this guide — what next? Apex stuttering after full optimization is usually one of three causes: shader compilation on first visit to an area (smooth on subsequent visits), RAM not running at XMP speed (check CPU-Z → Memory tab → Frequency should be half your rated kit speed), or running Apex from a hard drive rather than an SSD. The stuttering fix guide covers all three in detail.
